E460 E550 E690 low alloy high strength steel plate E460 E550 E690 manufacturer from China Tianjin Kilo steel&mechanical Co,. LTD

Place of Origin:

Tianjin, China (Mainland)

Product Detail

Model No.: E460 E550 E690

Width: 1200mm to 4000mm

Standard: En10025

Min Quantity: 20MT

Packageing Details: International standard

Thickness: 4mm to 150mm

Length: 3000mm to 18000mm

Payment: T/T, L/C

Trade terms: FOB,CIF,CFR

Delivery state: TMCP, Q& T, N, AR, CR, A, Q...

E460 E550 E690 low alloy high strength steel plate alloy high strength steel plate high strength steel plate high tensile steel pla

Chemicalcomposition [%{m/m}]
Grade	Quality	C max	Mn	Si	P Max	S Max	Othereelements
E460	DD E	0.20 0.20	0.7-1.7 0.7-1.7	<0.55 <0.55	0,035 0,030	0,035 0,030	Depending onthicknesses and manufacturing conditions, the manufacturer may find itnecessary to add on or serveral alloying element within the limits definedbelow:
E550	DD E	0.20 0.20	<=1.7 <=1.7	0,l to 0,80 0,lto 0.80	0,035 0,030	0,035 0,030
E690	DD E	0.20 0.20	<=1.7 <=1.7	0,l to 0,80 0,lto 0.80	0,035 0,030	0,035 0,030
1) At leastone of these grain-refining elements shall be present or aluminium shall beadded. In this case, the minimum total aluminium content shall be 0,020 % ( d m ) . 2) When thereis no stress-relieving treatment, a maximum content of 0.20 % ( d m ) ispermitted.

Grade	Quality	Specifiedyield strength (RpD,2) I min. N/m m2 ?)		Rln N/m m2	A21 min. %	KV 3 min. J
Grade	Quality	e<= 50	50			-20℃	-50℃
E460	DD E	460 460	440 440	570 to 720 570 to 720	17 17	39	27
E550	DD E	550 550	530 530	650 to 830 650 to 830	16 16	39	27
E690	DD E	690 690	670 670	770to940 770to940	14 14	39	27
RPo,*: 0.2 % proof stress; R,: tensile strength; A: percentage elongation after fracture on original gauge length L, =5,65& (where So is the original cross-sectional area); KV: impact strength of IS0 V-notch test pieces; e: thickness of test piece, in millimetres. 1) 1 N/mm2 = 1 MPa 2) The use of a test piece 200 mm long, elongation being measured on a gaugelength of 50 mm across the fracture, is permitted. However, in cases of dispute, only those results obtained on a proportionaltest piece shall be used. 3) Average of three tests; no individual result shall be less than 70 % ofthe specified minimum average value.
